Smith Fittings, located in Canberra, Australia, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Pipe and End Caps. Renowned for their precision, durability, and dependability, the company crafts products that ensure secure sealing and protection for piping systems. The Pipe and End Caps from Smith Fittings are designed to withstand pressure, corrosion, and mechanical stress, guaranteeing leak-proof performance and lasting durability. Catering to sectors like chemical processing, petrochemical, water treatment, and power generation, Smith Fittings provides products that adhere to international standards, delivering efficient, safe, and high-performance solutions for sealing and safeguarding pipelines in critical industrial settings.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: Pipe Caps
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: End Caps
These Pipe and End Caps are typically made from carbon steel, stainless steel, or alloy materials, which offer impressive strength, durability, and resistance to corrosion and mechanical stress. They boast excellent mechanical properties, including high tensile and yield strength, toughness, and the ability to endure internal pressure and temperature fluctuations. Built for stability and reliability, these components maintain their structural integrity even under demanding operating conditions, ensuring a safe and secure closure for pipelines.
Smith Fittings is a leading supplier of Pipe and End Cap in Canberra, Australia. We offer an extensive range of Pipe and End Cap, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Pipe and End Cap from Smith Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Pipe and End Caps offer several advantages, including their ability to provide a secure seal, preventing leaks and contamination in piping systems. Made from durable materials such as stainless steel and alloy steel, they are resistant to corrosion, high pressure, and extreme temperatures, ensuring long-lasting performance in various industrial applications. They are also easy to install and replace, making maintenance straightforward. Additionally, pipe and end caps enhance the structural integrity of the pipeline, helping to avoid costly repairs and downtime by protecting the system from external elements and internal damage.
Yes, custom sizes for Pipe and End Cap are available at Smith Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@smithfittings.com.
Stainless Steel Pipe Cap : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Pipe Cap : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel Pipe Cap : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel Pipe Cap : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex Pipe Cap : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy Pipe Cap : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel Pipe Cap : ASTM A420 WPL3, A420 WPL6
Stainless Steel End Cap : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel End Cap : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel End Cap : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel End Cap : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex End Cap : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy End Cap : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel End Cap : ASTM A420 WPL3, A420 WPL6
| Nominal Pipe Size | Outside diameter at bevel | Length(E) | Limitwall thickness |
| 1/2″ | 21.3 | 25 | 4.57 |
| 3/4″ | 26.7 | 25 | 3.81 |
| 1″ | 33.4 | 38 | 4.57 |
| 1 1/4″ | 42.2 | 38 | 4.83 |
| 1 1/2″ | 48.3 | 38 | 5.08 |
| 2″ | 60.3 | 38 | 5.59 |
| 2 1/2″ | 73.0 | 38 | 7.11 |
| 3″ | 88.9 | 51 | 7.62 |
| 3 1/2″ | 101.6 | 64 | 8.13 |
| 4″ | 114.3 | 64 | 8.64 |
| 5″ | 141.3 | 76 | 9.65 |
| 6″ | 168.3 | 89 | 10.92 |
| 8″ | 219.1 | 102 | 12.70 |
| 10″ | 273.0 | 127 | 12.70 |
| 12″ | 323.8 | 152 | 12.70 |
| 14″ | 355.6 | 165 | 12.70 |
| 16″ | 406.4 | 178 | 12.70 |
| 18″ | 457.0 | 203 | 12.70 |
| 20″ | 508.0 | 229 | 12.70 |
| 22″ | 559.0 | 254 | 12.70 |
| 24″ | 610.0 | 267 | 12.70 |
Widely utilized in industries that demand safe and efficient sealing of piping systems, Pipe and End Caps find common applications in chemical and petrochemical plants, oil and gas pipelines, water treatment facilities, power generation units, and industrial process lines. These components effectively close off the ends of pipes, shielding the system from contamination, leaks, and environmental exposure. With their leak-proof performance, structural integrity, and long service life, Smith Fittings’ Pipe and End Caps are indispensable for industrial applications where safety, durability, and operational efficiency are paramount.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
